AH25 Tray Packer

AH-M25 medium Speed Half-tray Packing Machine, developed from overlap sealing method, only one roll of film upload from machine bottom.matched hot melt glue system.

Compare to AH-L15 model, this model adopt two cylinders and 4 sets of servo motor to separate bottles/cans/cartons etc. maximum speed can reach 25 cases/minute.

available for both PE transparent film and Printed colorful film.

KOMAL AH-series additional pack strength or ease of handling, a cardboard pad or tray can be added under the product before being shrink wrapped.Model:AH25,capacity is 25-35bags/min. price is USD55,500-58,500/set.
Inquiry

Detailed Description:

  1. Mechanism rotation: the machine rotation drove by servo motor, adopt to synchronous belt and chain rotation assembly method, ensure rotation harmony, the place that adopt to chain ration all add protection covet and lubricate device, ensure worker safe and circumstance clean.
  2. Have the function: while lack bottle, the machine will alarm, no bottle no film feeding function.
  3. Controlling system: adopt to PLC and touch screen controlling, have manual. Auto move method, touch screen have full machine manipulation function, can display instant and accumulated package quantity, and enable can print with the connected printer. Setting procedure is more quick and precise; controlling panel adopt to electronics touch and control button controlling, can directly input and revise package type parameter, also can save different package specification parameter; timely supervise facility operation whole process. All the working procedure all have sensor checker, have ego diagnose function, if have any breakdown, facility will auto stop, alarm light blink, display breakdown type indication on the touch screen; common type reducer motor matching frequency transducer, whole machine limitless speed adjust, move transmission is very steadily; can as above situation change, auto control machine movement speed.
  4. Mechanism character: mechanism spare parts adopt to stainless steel, chroming steel and strong anti-corrode character aluminum alloy ect material; surface good quality spray printing, whole machine have strong anti-rust character.
  5. The facility accord with safe manipulation and safe operation related criterion and standard. All the lubricate part connect central place, for convenient to handle, lubricate part all ensure have no pollute on the product.

Basic Configuration:

No Name Number Brand Place of origin
1 Touch screen 1set INOVANCE



 China


2 Servo electric motor 4set
3 Servo controller 4set
4 PCC controlling system 1pcs
5 Manipulation plate 1pcs
6 Bus connector interface 1pcs
7 Input and output module 1piece
8 Photocell 10 sets AUTONICS Korea
9 Pneumatics 1pcs AIRTAC TAIWAN
10 Weather belt 2pcs Habsit Swiss
11 Frequency converter 2sets TECO TAIWAN
12 Hot glue machine 1set Robatech Switzerland

Technical Parameter:

  1.  Power supply. Total power : 380/220V ,60KW (three-phase )
  2. External gas source : 4-6kgf/cm2
  3. main motor: 380V 3300W
  4. Exit belt motor : 380V 750W
  5. Film feeding electricity motor: 3.3W
  6. Machine size (L*W*H) :12500*1500*2450mm
  7. Package piece speed : 25package /minute

Application Condition and Requirement:

  1. Package product size : can according to client special requirement.
  2. Working platform height ：1050-1100mm (can making according to special requirement).
  3. Usage film type : PE film
  4. PE film width PE: according to client requirement , film thickness: 0.07mm-0.13mm;
  5. Film shrinkage ratio : length wise direction 70-80%, cross wise 20-30%.
  6. Working flow: open power supply switch, cross film, choose manual film cutting, after one time film cutting success, then choose auto, machine start to operate. Product via bottle split flow facture, guiding fracture, bottle separate fracture, bottle handing film lifting up fracture, film wrapping fracture, at last via shrink tunnel, then finish whole film wrapping package working.
